系列 CM30

  1. Home
  2. 系列 CM30

用于极限情形的绝对值编码器

• 或多圈分辨率 可达12位

• 基于DIN EN 60529的IP65保护

• 外径90 mm

• 凸出轴

Product no longer available. Please contact us for more information

专家答疑

    Our team of experts will asnwer your technical, product or application questions as soon as possible.

    Name*

    E-mail*

    Phone

    Company

    Country

    Message

    HOHNER AUTOMATION S.L. as the data controller will process your data for the purpose of replying to your query or request. You may access, rectify and erase your data, and also exercise other rights by consulting the additional detailed information on data
    protection in our Privacy Policy.

    I have read and accept the conditions contained in the privacy policy on processing of my data to manage my query or request.

    We would like you to give us your consent to:

    Send you commercial information about HOHNER AUTOMATION S.L.’s products, services and new features

    Fields with a * are required.

      Plaease enter your email to download product Datasheet.

      E-mail

      HOHNER AUTOMATION S.L. as the data controller will process your data for the purpose of replying to your query or request. You may access, rectify and erase your data, and also exercise other rights by consulting the additional detailed information on data
      protection in our Privacy Policy.

      I have read and accept the conditions contained in the privacy policy on processing of my data to manage my query or request.

      We would like you to give us your consent to:

      Send you commercial information about HOHNER AUTOMATION S.L.’s products, services and new features

      Fields with a * are required.

        Name*

        E-mail*

        Phone

        Company

        Country

        Message

        HOHNER AUTOMATION S.L. as the data controller will process your data for the purpose of replying to your query or request. You may access, rectify and erase your data, and also exercise other rights by consulting the additional detailed information on data
        protection in our Privacy Policy.

        I have read and accept the conditions contained in the privacy policy on processing of my data to manage my query or request.

        We would like you to give us your consent to:

        Send you commercial information about HOHNER AUTOMATION S.L.’s products, services and new features

        Fields with a * are required.

        技 术 指 标
        外徑 90 mm
        机体 铝
        轴 不锈钢
        轴承 球
        轴承寿命 1×1010rev
        机械允许最大转数 6000 rpm
        DIN EN 60529的防尘和防飞溅 IP65
        转子惯量 270 gcm2
        20ºC (68ºF) 时的起动力矩 最大 5,0 Ncm
        轴向允许最大负荷 80 N
        径向允许最大负荷 100 N
        重量 1’3 kg
        工作温度范围 -10ºC 至 +70ºC
        振动 100 m/s2 (10Hz…2000Hz)
        撞击 1000 m/s2 (6ms)
        最大能耗 150 mA
        电源电压 10..30Vdc
        接口 模拟式
        输出电量 0..20mA, 0..10v, 4..20mA
        可设定参数 方向
        分辨率 10 或 12 位
        范围 4096 圈
        轴向或径向连接 2米电缆或工业连接器

        Accessories

        预装线缆

        法兰

        Union

        Cross-flex

        Alu-flex

        测量轮

        Bellow-flex

        连接器

        Spring-flex

        钟形耦合器

        Pagu-flex

        防旋转系统

        Poly-flex

        角架

        Oldham-flex-clamp

        Lami-flex

        SKU: CM30-23312215-1024128
